D11615PGJ is a bipolar junction transistor (BJT) designed specifically for high-speed applications. It is widely used in shaping circuits in cathode ray tube (CRT) televisions, switched mode power supplies (SMPS) and other industrial power circuits. This transistor is known for its high voltage between the emitter and collector, excellent switching characteristics, and high cooling capacity.
The D11615PGJ from Renesas Electronics (formerly NEC) is part of a series of advanced transistors that support both conventional and modern power supply designs.
🔧 Technical specifications D11615PGJ
Features Specifications
Part number D11615PGJ
Type NPN transistor
Package TO-3P (through-hole)
Collector-emitter voltage 1500 V (V<sub>CEO</sub>)
Collector current maximum 8 A (I<sub>C</sub>)
Power consumption 80 W at Tc = 25 °C
Constant current (hFE) 5–40 at Ic = 4 A, Vce = 5 V
Switching frequency 4 MHz
Operating temperature –55 °C to +150 °C
📄 Download the sample data sheet or technical brochure (external link)
⚙️ Main features
- 🔋 High voltage resistance – 1500 V V<sub>CEO</sub>, suitable for demanding industrial applications
- ⚡ Fast operating speed – switching frequency 4 MHz
- 🔧 High processing capacity – heat dissipation up to 80 W
- 📦 TO-3P package – suitable for through-hole designs with heat sinks
🧰 Typical applications
1. CRT horizontal deflection
Due to its high switching speed and high voltage resistance, it is used in the horizontal output stages of older televisions and monitors.
2. Switching power supply (SMPS)
Thanks to its high start-up/run-down speed and high voltage, it is suitable for power conversion applications such as transformers (inverters or positive).
3. Reverse high current circuit
Suitable for inverters and motors that require reliable performance under thermal and electrical stress.
4. Induction motor
Suitable for industrial automation circuits that drive inductive loads (e.g., coils, motors, electromagnetic valves).
🛒 Buy D11615PGJ from DRex Electronics
At DRex Electronics, we specialize in the purchase of heavy transistors, including models that are difficult to obtain or no longer manufactured, such as the D11615PGJ. We provide fast and reliable delivery of components for the telecommunications, automotive, industrial automation and other industries.
Why choose DRex?
- ✅ ISO 9001:2015 certified
- 🌍 Global purchasing network
- 📦 Stock includes older models and models in production
- 🛠️ Technical support and bill of materials compliance
➡️ Request a quote for D11615PGJ orbrowse other power transistors.
